Description
Specs
Aircraft
Weight (Battery & Propellers Included)1280 g
Diagonal Size (Propellers Excluded)350 mm
Max Ascent Speed5 m/s
Max Descent Speed3 m/s
Max Speed16 m/s (ATTI mode)
Max Pitch Angle35°
Max Angular Speed150°/s
Max Service Ceiling Above Sea Level19685 feet (6000 m)
Max Flight TimeApprox. 23 minutes
Operating Temperature Range32° to 104°F (0° to 40°C)
Satellite Positioning SystemsGPS/GLONASS
Hover Accuracy RangeVertical:
±0.1 m (with Vision Positioning)
±0.5 m (with GPS Positioning)
Horizontal:
±0.3 m (with Vision Positioning)
±1.5 m (with GPS Positioning)
±0.1 m (with Vision Positioning)
±0.5 m (with GPS Positioning)
Horizontal:
±0.3 m (with Vision Positioning)
±1.5 m (with GPS Positioning)
Camera
Sensor1/2.3” CMOS
Effective pixels: 12.4 M (total pixels: 12.76 M)
Effective pixels: 12.4 M (total pixels: 12.76 M)
LensFOV 94° 20 mm (35 mm format equivalent) f/2.8 focus at ∞
ISO Range
- 100-3200 (video)
- 100-1600 (photo)
Electronic Shutter Speed8 – 1/8000 s
Image Size4000×3000
Still Photography Modes
- Single Shot
- Burst Shooting: 3/5/7 frames
- Auto Exposure Bracketing (AEB): 3/5 bracketed frames at 0.7 EV Bias
- Timelapse
Video Recording Modes
- UHD: 4096x2160p 24/25, 3840x2160p 24/25/30
- FHD: 1920x1080p 24/25/30/48/50/60
- HD: 1280x720p 24/25/30/48/50/60
Max Video Bitrate60 Mbps
Supported File SystemsFAT32 (≤32 GB); exFAT (>32 GB)
PhotoJPEG, DNG (RAW)
VideoMP4, MOV (MPEG-4 AVC/H.264)
Supported SD CardsMicro SD
Max capacity: 64 GB
Class 10 or UHS-1 rating required
Max capacity: 64 GB
Class 10 or UHS-1 rating required
Operating Temperature Range32° to 104°F (0° to 40°C)
Gimbal
Stabilization3-axis (pitch, roll, yaw)
Controllable RangePitch: -90° to +30°
Max Controllable Angular SpeedPitch: 90°/s
Angular Control Accuracy±0.02°
Vision System
Vision SystemDownward Vision System
Velocity Range≤8 m/s (2 m above ground)
Altitude Range30 – 300 cm
Operating Range50 – 300 cm
Operating EnvironmentSurface with clear pattern and adequate lighting (lux>15)
Remote Controller
Operating Frequency2.400 – 2.483 GHz
Max Transmission DistanceFCC Compliant: 3.1 mi (5 km)
CE Compliant: 2.2 mi (3.5 km)
(Unobstructed, free of interference)
CE Compliant: 2.2 mi (3.5 km)
(Unobstructed, free of interference)
Operating Temperature Range32° to 104°F (0° to 40°C)
Battery6000 mAh LiPo 2S
Transmitter Power (EIRP)
- FCC: 20 dBm
- CE: 16 dBm
- MIC: 16 dBm
Operating Current/Voltage1.2 A@7.4 V
Video Output PortUSB
Mobile Device HolderTablets and smart phones
Charger
Voltage17.4 V
Rated Power100 W
Intelligent Flight Battery
Capacity4480 mAh
Voltage15.2 V
Battery TypeLiPo 4S
Energy68 Wh
Net Weight365 g
Charging Temperature Range41° to 104°F (5° to 40°C)
Max Charging Power100 W
App / Live View
Mobile AppDJI GO
Live View Working Frequency2.4 GHz ISM
Live View Quality720P @ 30fps
Latency220ms (depending on conditions and mobile device)
Required Operating Systems
- iOS 8.0 or later
